Trane CGAM User Manual

CG-SVX17D-EN 137
Controls Interface
A couple of additional tabs in Configuration View allow you to change other unit configuration
options using the Options tab and the Options Setup tab. The features that are installed on the
Options Tab will control what is displayed on the Options Setup tab.
Table 58. Configuration View Items - CH530 Tab
Item Description
Basic Product Line
CGAM - Air-Cooled Scroll Packaged Chiller
CXAM - Air-Cooled Scroll Heat Pump (TAI, EPL only)
Unit Capacity
020 Nominal Tons
023 Nominal Tons (TAI, EPL only)
026 Nominal Tons
030 Nominal Tons
035 Nominal Tons
039 Nominal Tons (EPL only)
040 Nominal Tons
045 Nominal Tons (EPL only)
046 Nominal Tons (TAI, EPL only)
052 Nominal Tons
060 Nominal Tons
070 Nominal Tons
080 Nominal Tons
090 Nominal Tons
100 Nominal Tons
110 Nominal Tons
120 Nominal Tons
Unit Design Sequence Factory Assigned
Manufacturing Location
Epinal, France
Pueblo, USA
Taicang, China
Curitiba, Brazil
Unit Type
Standard Efficiency/Performance (EPL only)
High Efficiency/Performance
Sound Package
High Duty (EPL and TAI only)
Standard Noise
Low Noise
Supply Power Frequency
60 Hz
50 Hz
Unit Application
Standard Ambient (EPL and TAI only)
Low Ambient (EPL and TAI only)
High Ambient (EPL and TAI only)
Wide Ambient
Heat Recovery
No Heat Recovery
Partial Heat Recovery w/ Fan Control
Partial Heat Recovery w/o Fan Control (EPL and TAI only)
Evaporator Pump Control
No Pump Flow Control
Single Pump Fixed Speed (TAI, EPL only)
Single Pump Variable Speed (TAI, EPL only)
Dual Pump Fixed Speed (TAI, EPL only)
Dual Pump Variable Speed
