Trane CGAM User Manual

CG-SVX17D-EN 73
Installation - Electrical
Electrical Data Tables
Table 30. Electrical Data - 60 Hz
Unit
Size Rated
Power
Number
Circuits
Qty
Comp
Qty
Fans
Fan
Motor
Power
(kw)
Cond
Fan
FLA
Compressor
RLA¹
Compressor
LRA²
No pump Pump
MCA MOPD MCA MOP
20
208/60/3 1 2 2 1 6.2 39-39 267-267 106 125 122 150
230/60/3 1 2 2 1 6.7 39-39 267-267 106 125 122 150
380/60/3 1 2 2 1 3.7 22-22 160-160 60 80 n/a
460/60/3 1 2 2 1 3.2 19-19 142-142 51 60 64 80
575/60/3 1 2 2 1 2.6 15-15 103-103 42 50 52 60
26
208/60/3 1 2 2 1 6.2 51-51 315-315 131 175 148 175
230/60/3 1 2 2 1 6.7 44-44 315-315 117 150 134 175
380/60/3 1 2 2 1 3.7 26-26 177-177 69 90 n/a
460/60/3 1 2 2 1 3.2 21-21 158-158 56 70 69 80
575/60/3 1 2 2 1 2.6 19-19 126-126 50 60 59 70
30
208/60/3 1 2 3 1 6.2 53-53 320-320 143 175 160 200
230/60/3 1 2 3 1 6.7 54-54 320-320 146 175 153 200
380/60/3 1 2 3 1 3.7 31-31 210-210 83 110 n/a
460/60/3 1 2 3 1 3.2 26-26 160-160 70 90 83 100
575/60/3 1 2 3 1 2.6 21-21 135-135 57 70 66 80
35
208/60/3 1 2 3 1 6.2 53-74 320-485 169 225 186 250
230/60/3 1 2 3 1 6.7 54-67 320-485 162 225 175 225
380/60/3 1 2 3 1 3.7 31-40 210-260 94 125 n/a
460/60/3 1 2 3 1 3.2 26-33 160-215 79 110 92 110
575/60/3 1 2 3 1 2.6 21-26 135-175 64 90 73 90
40
208/60/3 2 4 4 1 6.2 39-39/39-39 267-267/267-267 197 225 214 250
230/60/3 2 4 4 1 6.7 39-39/39-39 267-267/267-267 198 225 214 250
380/60/3 2 4 4 1 3.7 22-22/22-22 160-160/160-160 112 125 n/a
460/60/3 2 4 4 1 3.2 19-19/19-19 142-142/142-142 95 110 108 125
575/60/3 2 4 4 1 2.6 15-15/15-15 103-103/103-103 79 90 89 100
52
208/60/3 2 4 4 1 6.2 51-51/51-51 315-315/315-315 246 250 263 300
230/60/3 2 4 4 1 6.7 44-44/44-44 315-315/315-315 220 250 237 250
380/60/3 2 4 4 1 3.7 26-26/26-26 177-177/177-177 129 150 n/a
460/60/3 2 4 4 1 3.2 21-21/21-21 158-158/158-158 106 125 119 125
575/60/3 2 4 4 1 2.6 19-19/19-19 126-126/126-126 93 110 103 110
60
208/60/3 2 4 6 1 6.2 53-53/53-53 320-320/320-320 269 300
n/a230/60/3 2 4 6 1 6.7 50-50/50-50 320-320/320-320 259 300
380/60/3 2 4 6 1 3.7 31-31/31-31 210-210/210-210 157 175
460/60/3 2 4 6 1 3.2 26-26/26-26 160-160/160-160 132 150 148 150
575/60/3 2 4 6 1 2.6 21-21/21-21 135-135/135-135 107 125 118 125
70
208/60/3 2 4 6 1 6.2 53-74/74-54 320-485/485-320 316 350
n/a230/60/3 2 4 6 1 6.7 50-67/67-50 350-485/485-350 297 350
380/60/3 2 4 6 1 3.7 31-40/40-31 210-260/260-210 117 200
460/60/3 2 4 6 1 3.2 26-33/33-26 160-215/215-160 148 175 164 175
575/60/3 2 4 6 1 2.6 21-26/26-21 135-175/175-135 120 125 131 150
