CG-SVX17D-EN 55
Installation - Mechanical
Evaporator Label
The BPHE evaporator label, including barcode, is located under the insulation, in the locations
shown in Figure 43, p. 55. Insulation backing over this area has not been removed, so that it can
be rolled back to access BPHE label.
Figure 43. BPHE label locations
BPHE LABEL LOCATION
BARCODE
ADDITIONAL INSULATION TAP
BPHE LABEL LOCATION
BARCODE
ADDITIONAL INSULATION TAP
26/30/36T BPHE - P120
20T BPHE - P80
BPHE LABEL LOCATION
BARCODE
ADDITIONAL INSULATION TAP
ROLL BACK THE INSULATION
ADDITIONAL INSULATION TAP
BPHE LABEL LOCATION
BARCODE
ROLL BACK THE INSULATION
52-130T BPHE - DP400
40T BPHE - DP200
