8 CG-SVX17D-EN
Model Number Description
Overview
This manual covers the installation, operation and maintenance of the CGAM units.
Nameplates
The CGAM unit nameplates are applied to the exterior surface of the control panel door
for 20-70 Ton sizes. The 80-120 Ton sizes have a nameplate on a support beam to the right
side of the starter panel.
A compressor nameplate is located on each compressor.
Unit Nameplate
The unit nameplate provides the following information:
• Unit model and size descriptor.
• Unit serial number.
• Identifies unit electrical requirements.
• Lists correct operating charges of R-410A and refrigerant oil.
• Lists unit design pressures.
• Identifies installation, operation and maintenance and service data literature.
• Lists drawing numbers for unit wiring diagrams.
Figure 1. Unit Nameplate
X39003199010C
MODEL NUMBER
FOR OUTDOOR USE
SERIAL NUMBER
CHARGED
CKT 1
TYPE/
NUMBER
REFRIGERANT
MIN CKT
AMPACITY (A)
MAX FUSE/
BREAKER (A)
RFGT CHARGE OIL CHARGE
CKT 1 (LBS) CKT 1 (GAL)
CKT 2
CKT 2 (LBS) CKT 2 (GAL)
COMPR
MTR 1A
RLA LRA
COMPR
MTR 1B
HIGH
SIDE
DESIGN PRESSURES (PSI)
WIRING DIAGRAM BOOK
LOW
SIDE
INSTALLATION, OPERATION
& MAINTENANCE MANUAL
5,056,594 5,067,560 5,123,256 5,138,844 5,231,846 5,276,630 5,419,146 5,632,154 5,809,794 5,950,443 6,049,299
6,085,532 6,266,964 6,276,152 6,666,042 6,917,857 7,020,156 7,088,346 7,158,121 7,202,858 7,385,593
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS/
CORRESPONDING FOREIGN PATENTS OWNED BY TRANE.
MADE IN USATRANE
COMPR
MTR 1C
COMPR
MTR 2A
COMPR
MTR 2B
COMPR
MTR 2C
FIXED SPEED
FAN MOTORS
QTY
2 SPEED
FAN MOTORS
VFD
CONTROLLED
FAN MOTORS
QTY
HP EA FLA EA
VFD INPUT AMPS
RLA LRA
RATED
VOLTAGE/HZ/PH
VOLT UTILIZATION
RANGE
CKT 3 FREEZE
PROTECTION
HEATERS
CKT 4 BUFFER
TANK HEATER
* PUMP
MOTORS
QTY
WATTS
RATED
VOLTAGE/HZ/PH
VOLT UTILIZATION
RANGE
MIN CKT
AMPACITY (A)
MAX FUSE/
BREAKER (A)
WATTS
* EXCLUSIVELY INTERLOCKED
MTR VOLT
HP EA FLA EA
HP EA FLA EA
VFD INPUT AMPS
