Trane CGAM User Manual

CG-SVX17D-EN 17
General Data
Table 2. General Data - 60 Hz - SI
Size 20 26 30 35 40 52 60 70 80 90 100 110 120 130
Compressor
Number#22224444444446
Tonnage/circuit¹ 10+10 13+13 15+15 15+20 10+10 13+13 15+15 15+20 20+20 20+25 25+25 25+30 30+30
20+20
+25
Evaporator
Water storage (l) 5.3 8.3 8.3 12.1 9.1 15.5 18.9 28.4 26.5 34.1 39.0 43.5 43.5 46.6
Min. flow² (l/s) 1.5 1.9 2.1 2.5 2.9 3.7 4.2 5.0 5.8 6.5 7.3 7.9 8.6 9.3
Max. flow² (l/s) 4.4 5.6 6.3 7.4 8.6 11.1 12.7 15.1 17.4 19.4 21.9 23.7 25.7 27.8
Water connection (mm) 50.8 63.5 63.5 63.5 76.2 76.2 76.2 76.2 101.6 101.6 101.6 101.6 101.6 101.6
Pump Package
Avail head pressure (kPa) 239.4 236.4 217.6 210.7 200.6 176.4 235.2 198.5 188.9 177.3 214.9 194.3 226.3 191.0
Power (HP) 5.0 5.0 5.0 5.0 5.0 5.0 7.6 7.6 10.2 10.2 10.2 10.2 15.2 15.2
Expansion tank
volume
(l) 18.9 18.9 18.9 18.9 18.9 18.9 18.9 18.9 22.7 22.7 22.7 22.7 22.7 22.7
Buffer Tank
Buffer tank volume (l) 116 116 116 116 116 116 116 116 127 127 162 162 162 162
Condenser
Quantity of coils#11112222444444
Coil length (mm) 2311 2311 3226 3226 2311 2311 3226 3226 3073 3073 3658 3658 3658 4572
Coil height (mm) 1727 1727 1727 1727 1727 1727 1727 1727 1067 1067 1067 1067 1067 1067
Number of rows#22222222333333
Fins per foot (fpf) 192 192 192 192 192 192 192 192 192 192 192 192 192 192
Fan
Quantity/circuit¹#2233223323444
Diameter (mm) 732 732 732 732 732 732 732 732 732 732 732 732 732 732
Airflow per fan
(m³/
h)
15993 16005 15577 15585 15993 16005 15577 15585 16090 16093 15451 15454 15458 15451
Power per motor (kW) 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2
Motor RPM (rpm) 840 840 840 840 840 840 840 840 840 840 840 840 840 840
Tip speed (m/s) 32 32 32 32 32 32 32 32 32 32 32 32 32 32
General Unit
Refrig circuits#11112222222222
Capacity steps % 50-100 50-100 50-100 43-100
25-50-
75-100
25-50-
75-100
25-50-
75-100
21-43-
71-100
25-50-
75-100
22-44-
72-100
25-50-
75-100
23-45-
73-100
25-50-
75-100
15-31-
46-62-
81-100
Refrig charge/
circuit¹
(kg) 14.5 15.4 21.8 21.8 14.5 14.5 22.9 21.8 33.6 35.4 40.8 41.5 39.0 50.8
Oil charge /circuit¹ (l) 6.4 6.4 13.2 13.2 6.4 6.4 13.2 13.2 13.2 13.2 13.2 14 14.4 22.0
Min ambient (°C) -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18
1. Data shown for circuit one only. The second circuit always matches.
2. Flow limits are for water only.
