CG-SVX17D-EN 37
Unit Dimensions/Weights
Figure 32. CGAM 40 and 52 ton- pump package, buffer tank, partial heat recovery unit water connections
Pump Package
Partial Heat Recovery
Partial heat recovery connections are even with unit end.
Water outlet connection is even with unit end,
inlet is 6.1 in (154 mm) from unit end.
The chilled water connections are the same as the standard
unit unless pump package or buffer tank are ordered.
Buffer Tank
Chilled
water
inlet
Chilled
water
outlet
19.7in
(500mm)
(474mm) 18.7in
70.4 in (1788 mm)
19.7in
(500mm)
Chilled water
inlet
Chilled water
outlet
19.7in
(499mm)
18.7in (474 mm)
66.8 in (1696 mm)
9.2 in
(234mm)
Heating outlet
Heating inlet
54.8in
(1392mm)
45.4in
(1153mm)
44.2in
(1122mm)
Water inlet connect is even with unit end,
outlet is recessed 14.8 in (376 mm) from unit end.
Figure 33. CGAM 60 and 70 ton- pump package, buffer tank, partial heat recovery unit water connections
Pump Package
Partial Heat Recovery
Partial heat recovery connections are even with unit end.
Water outlet connection is even with unit end,
inlet is 6.1 in (154 mm) from unit end.
The chilled water connections are the same as the standard
unit unless pump package or buffer tank are ordered.
Buffer Tank
Chilled
water
inlet
Chilled
water
outlet
19.7in
(500mm)
(474mm) 18.7in
70.4 in (1788 mm)
19.7in
(500mm)
Chilled water
inlet
Chilled water
outlet
19.7in
(499mm)
18.7in (474 mm)
66.8 in (1696 mm)
9.2 in
(234mm)
Heating outlet
Heating inlet
55.2in
(1402mm)
45.6in
(1158mm)
44.2in
(1122mm)
Water inlet connect is even with unit end,
outlet is recessed 14.8 in (376 mm) from unit end.
