24 Wireless Zone Sensor • BAS-SVX04A-EN
Setting the Address, Mounting, Wiring, and Associating the
Receiver and Sensor
Replacing and Securing the Receiver Cover
1. To replace the receiver cover on the base plate, hook the cover over the top of
the base plate. Apply light pressure to the bottom of the cover until it snaps
in place.
2. If necessary to keep the cover securely attached, install the security screw
into the bottom of the receiver (
Figure 10).
Figure 10. Snap receiver cover on base plate and attach security screw
Security screw
