Operation, Maintenance, and Troubleshooting
Diagnostics
LED1, LED2, and LED3 will respond to diagnostics by exhibiting specific blinking
patterns. They will occur on the sensor as a result of pressing the Test button (S5)
(Tab l e 5). They will occur on the receiver independently of any user action
(Tab l e 6).
Table 5. Diagnostics: LED1, LED2, LED3 on the sensor
User action LED display
i
Indicates...
Press Test
button (S5)
LED1: Off
LED2: Off
LED3: 1-blink pattern repeated 3 times
Disassociated
• Sensor is not associated with a receiver.
LED1: Off
LED2: Off
LED3: 2-blink pattern repeated 3 times
Address set to 000
• Address not set to between 001–999.
LED1: Off
LED2: Off
LED3: 3-blink pattern repeated 3 times
Not configured
• Sensor configuration properties not properly set
(defective sensor).
LED1: Off
LED2: Off
LED3: 4-blink pattern repeated 3 times
Input voltage too high
• No RF transmission is permitted with an input battery
voltage greater than 3.9 V.
i
Blink pattern is On for 1/4 s, Off for 1/4 s, with 2 s Off between repetitions.
Table 6. Diagnostics: LED1, LED2, LED3 on the receiver
User action LED display
i
Indicates...
None LED1: Off
LED2: Off
LED3: 3-blink pattern repeated 3 times
Disassociated
• Receiver is not associated, waiting for a sensor.
• Receiver lost communication with sensor.
• Receiver has no devices on its wireless personal area
network.
• Association with a device has been manually removed.
LED1: Off
LED2: Off
LED3: 2-blink pattern repeated continuously
Address set to 000
• Address not set to between 001–999.
LED1: Off
LED2: Off
LED3: 3-blink pattern repeated 3 times
Not configured
• Receiver configuration properties not properly set
(defective receiver).
i
Blink pattern is On for 1/4 s, Off for 1/4 s, with 2 s Off between repetitions.
