Triumph Speed Twin 2019 User Manual

Maintenance and Adjustment
106
Caution
If the engine oil pressure is too low,
the low oil pressure warning light will
illuminate. If this light stays on when
the engine is running, stop the engine
immediately and investigate the cause.
Running the engine with low oil
pressure will cause engine damage.
• Turn the ignition OFF, check the
engine oil level using the method
previously described, and top off
to between the minimum and
maximum level lines in the sight
glass.
Disposal of Used Engine Oil and Oil
Filters
To protect the environment, do not
pour oil on the ground, down sewers or
drains, or into groundwater sources. Do
not place used oil filters in with general
waste. If in doubt, contact your local
authority.
Engine Oil Specification and Grade
Triumph's high performance fuel
injected engines are designed to
use 10W/40 or 10W/50 semi or fully
synthetic motorcycle engine oil that
meets specification API SH (or higher)
and JASO MA, such as Castrol Power
1 Racing 4T 10W-40 (fully synthetic)
engine oil, sold as Castrol Power RS
Racing 4T 10W-40 (fully synthetic) in
some countries.
Refer to the chart below for the correct
oil viscosity (10W/40 or 10W/50) to be
used in your riding area.
Oil Viscosity Temperature Range
Do not add any chemical additives
to the engine oil. The engine oil also
lubricates the clutch and any additives
could cause the clutch to slip.
Do not use mineral, vegetable, non-
detergent oil, castor based oils or any
oil not conforming to the required
specification. The use of these oils may
cause instant, severe engine damage.
Make sure that no foreign matter enters
the crankcase during an engine oil
change or top off.

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
