Triumph Speed Twin 2019 User Manual

General Information
45
Clock
To access the clock, press and release
the SCROLL button, located on the left
hand handlebar switch housing, until
the clock is shown.
10
20
3
0
110
120
120
0
0
20
40
160
180
200
1
1. Clock
Clock Adjustment
Warning
Do not attempt to adjust the clock
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
To reset the clock:
• Select the clock display.
• Press and hold the SCROLL button
for one second, the clock’s hour
display will start to flash. Release
the SCROLL button.
To reset the hour display:
• Make sure the hour display is still
flashing then press and release
the SCROLL button to change the
setting. Each individual button press
will change the setting by one digit.
• When the correct hour display is
shown, press and hold the SCROLL
button for one second. The hours
display is set and the minutes
display will begin to flash. The
minutes display is adjusted in the
same way as for the hour display.
• Once both hours and minutes are
correctly set, press the SCROLL
button for one second and the
display will cease to flash.

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
