Triumph Speed Twin 2019 User Manual

Maintenance and Adjustment
147
Turn Signal Lights
The motorcycle is equipped with either
LED or bulb turn signal lights.
LED Turn Signal Lights
The LED turn signal light units are
sealed, maintenance free LED units.
The turn signal light assembly must be
replaced in the event of the failure of
the turn signal.
Street Scrambler and Street Twin
Turn Signal Bulb Replacement
1
3
2
1. Lens
2. Bulb
3. Turn signal lens screw
The lens on each turn signal light is
held in place by an indicator lens screw
located in the body of the light unit.
To replace the turn signal light bulb:
• Loosen the turn signal lens screw
and remove the lens to gain access
to the bulb for replacement.
• Carefully remove the bulb and
replace it with a new bulb.
• Installation is the reverse of the
removal procedure.
Bonneville T100, Bonneville T120,
Thruxton and Thruxton R Turn
Signal Bulb Replacement
3
21
1. Bulb
2. Locating tangs
3. Lens
To replace the turn signal light bulb:
• Carefully twist the lens
counterclockwise and remove from
the turn signal to gain access to the
bulb.
• Gently press the bulb inwards and
twist counterclockwise. Replace with
a new bulb.
• Installation for the bulb is the
reverse of the removal procedure.
Caution
When installing the lens, make sure
that the locating tangs are correctly
aligned to the turn signal body.
• To install the indicator lens, align the
locating tangs with the turn signal
body and twist counterclockwise to
secure.

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
