Triumph Speed Twin 2019 User Manual

General Information
42
Fuel Gauge
Street Scrambler and Street Twin
Only
10
20
30
1
00
110
120
120
0
0
20
40
60
140
160
180
200
21
1. Low fuel indicator light
2. Fuel gage
All Other Models
1
2
1. Fuel gage
2. Low fuel indicator light
The fuel gage indicates the amount
of fuel in the tank. With the ignition
switched on, the number of bars shown
in the display indicates the level of fuel.
When the fuel tank is full all eight bars
are displayed and when empty, no bars
are displayed. Other gage markings
indicate intermediate fuel levels
between full and empty.
When there are approximately 0.8 US
gallons (3.0 liters) of fuel remaining in
the tank, the low fuel warning light will
illuminate.
Note
After refueling, the fuel gage and range
to empty information will be updated
only while riding the motorcycle.
Depending on the riding style, updating
could take up to five minutes.
Range to Empty
Street Scrambler and Street Twin
Only
10
20
110
120
120
0
0
20
40
0
180
200
21
1. Range to empty indicator
2. Estimated distance remaining

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
