Triumph Speed Twin 2019 User Manual

Maintenance and Adjustment
112
Clutch Adjustment
To adjust the clutch:
• Turn the adjuster sleeve until the
correct amount of clutch lever free
play is achieved.
• Check that there is 0.08 - 0.12 in (2
- 3 mm) clutch lever free play at the
lever.
• If there is an incorrect amount of
free play, adjustments must be
made.
1
2 - 3 mm
2
3
1. Clutch lever
2. Adjuster sleeve (lock nut fully loosened)
3. Correct clearance 0.08 - 0.12 in (2 - 3 mm)
If correct adjustment cannot be made
using the lever adjuster, use the cable
adjuster at the lower end of the cable.
• Loosen the adjuster lock nut.
• Turn the outer cable adjuster to give
0.08 - 0.12 in (2 - 3 mm) of free play
at the clutch lever.
• Tighten the lock nut to 31 lbf in
(3.5 Nm).
312
1. Adjuster nut
2. Lock nut
3. Clutch cable

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
