Parts Identification
16
Parts Identification
Bonneville T100, Bonneville T120, Bonneville T120 Ace and
Bonneville T120 Diamond (Bonneville T120 shown)
1
2
3
4
5
6
7
8
91 0111213
14
15
16
17
1. Front turn signal
2. Headlight
3. Clutch lever
4. Battery (under seat)
5. Owner’s Handbook (under seat) or
supplied separately
6. Brake/tail light
7. Rear turn signal
8. Rear brake disc
9. Rear brake caliper
10. Coolant expansion tank
11. Coolant expansion tank cap
12. Side stand
13. Gear shift pedal
14. Horn
15. Radiator
16. Front brake caliper
17. Front brake disc

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
