Triumph Speed Twin 2019 User Manual

General Information
65
Refueling
Warning
To help reduce hazards associated
with refueling, always observe the
following fuel safety instructions:
- Gasoline (fuel) is highly flammable
and can be explosive under certain
conditions. When refueling, turn the
ignition switch to the OFF position.
- Do not smoke.
- Do not use a mobile telephone.
- Make sure the refueling area is well
ventilated and free from any source
of flame or sparks. This includes any
appliance with a pilot light.
- Never fill the tank until the fuel level
rises into the filler neck. Heat from
sunlight or other sources may cause
the fuel to expand and overflow
creating a fire hazard.
- After refueling always check that the
fuel filler cap is correctly closed.
- Because gasoline (fuel) is highly
flammable, any fuel leak or spillage,
or any failure to observe the safety
advice given above will lead to a fire
hazard, which could cause damage to
property, injury to persons or death.
Fuel Tank Cap
1
1. Fuel tank cap
To open the fuel tank cap:
• Remove the cover or lift up the flap.
• Insert the key into the lock and turn
the key clockwise.
• Rotate the cap counterclockwise
and lift clear of the tank filler neck.
To close and lock the cap:
• Align the cap to the tank filler neck
and rotate the cap clockwise until
the cap seals against the filler neck.
• In the fully closed position, a ratchet
mechanism prevents overtightening
of the cap by allowing the outer part
of the cap to turn independently of
the internal part.
• Turn the key counterclockwise to
lock and withdraw the key.
• Replace the cover or securely close
the flap.

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
