Triumph Speed Twin 2019 User Manual

Maintenance and Adjustment
127
Front Suspension Preload
Adjustment - Thruxton R Only
The preload adjuster is located at the
bottom of the front suspension unit.
ciys
1
1. Front suspension preload adjuster
To adjust the preload setting:
• Rotate the adjuster clockwise to
increase, or counterclockwise to
decrease using the adjustment tool
located in the right hand side panel.
• Always count the number of turns
from the fully clockwise position.
Front Suspension Rebound and
Compression Damping Adjustment -
Thruxton R Only
The rebound and compression damping
adjusters are located at the top of each
fork.
ciyt
Front Suspension Rebound and
Compression Damping Adjusters
To adjust the rebound damping setting:
• Rotate the TEN slotted adjuster
clockwise to increase, or
counterclockwise to decrease.
• Always count the number of turns
from the fully clockwise position.
To adjust the compression damping
setting:
• Rotate the COM slotted adjuster
clockwise to increase, or
counterclockwise to decrease.
• Always count the number of turns
from the fully clockwise position.

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
