Triumph Speed Twin 2019 User Manual

General Information
70
Tool Kit and Owner’s
Handbook
Tool Kit
The tool kit consists of an adjustment
tool for all models, and additional
C-spanners for Thruxton R.
1
1. Adjustment tool
Bonneville T100, Bonneville T120,
Bonneville T120 Ace,
Bonneville T120 Diamond,
Speed Twin, Street Twin, Thruxton
and Thruxton R
The adjustment tool is attached to the
inside of the right hand side panel.
Street Scrambler
The adjustment tool is attached to the
inside of the left hand side panel.
Thruxton R
There are two C-spanners located under
the seat.
Owner’s Handbook
Bonneville T100, Bonneville T120,
Bonneville T120 Diamond, Thruxton
and Thruxton R
The Owner’s Handbook is located under
the seat on the rear fender.
Bonneville T120 Ace, Speed Twin
and Street Scrambler
The Owner’s Handbook is supplied
separately.
Street Twin
The Owner’s Handbook is located on the
underside of the seat.

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
