Triumph Speed Twin 2019 User Manual

General Information
52
Tire Pressure Monitoring
System (TPMS) (if equipped)
Warning
The daily check of tire pressures
must not be excluded because of the
installation of the TPMS. Check the tire
pressure when the tires are cold using
an accurate tire pressure gage (see
page 133).
Use of the TPMS system to set
inflation pressures may lead to
incorrect tire pressures leading to loss
of motorcycle control and an accident.
Note
Tire Pressure Monitoring System (TPMS)
is an accessory option only available on
models equipped with cast alloy wheels.
Function
Tire pressure sensors are mounted
to the front and rear wheels. These
sensors measure the air pressure inside
the tire and transmit pressure data to
the instruments. These sensors will not
transmit the data until the motorcycle
is traveling at a speed greater than
12 mph (20 km). Two dashes will be
shown in the display screen until the
tire pressure signal is received.
The Tire Pressure Monitoring System
(TPMS) is an accessory equipped
item and must be installed by your
authorized Triumph dealer.
The TPMS display screen on the
instruments will only be activated when
the system has been installed.
An adhesive label will be installed to the
wheel rim to indicate the position of the
tire pressure sensor which is near the
valve.
Tire Pressure Sensor Serial Number
The serial number for the tire pressure
sensor is printed on a label attached
to the sensor. This number may be
required by your authorized Triumph
dealer for service or diagnostics.
When the tire pressure monitoring
system is being installed to the
motorcycle, make sure that your
authorized Triumph dealer records the
serial numbers of the front and rear tire
pressure sensors in the spaces provided
below.
Front Tire Pressure Sensor
Rear Tire Pressure Sensor

Triumph Speed Twin 2019 Specifications

General

Displacement	1200 cc
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Frame	Tubular steel cradle
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Seat Height	807 mm
Dry Weight	196 kg
Wet Weight	216 kg
Fuel Tank Capacity	14.5 liters
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Exhaust	Stainless steel 2 into 2 exhaust system with twin silencers
Final Drive	Chain
Front Suspension	120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston floating caliper, ABS
Front Wheel	Cast aluminium
Rear Wheel	Cast aluminum
Wheelbase	1, 410mm
Max Power	97 PS / 96 bhp (71.5 kW) @ 6, 750 rpm
