Triumph Thruxton Handbook

100
Maintenance and Adjustment
Headlight/Position Light Bulb
Replacement
1. Headlight rim screws (1 of 2)
2. Headlight bowl
• Disconnect the battery, negative
(black) lead first.
• Remove the headlight rim screws.
• Detach the headlight and rim
assembly from the headlight bowl.
• While supporting the light unit,
disconnect the multi-pin electrical
connector from the headlight bulb
and the two spade connectors from
the position light.
• Remove the rubber dust cover.
• Unhook the headlight bulb's wire
retainer.
• The headlight bulb can now be
removed.
• To remove the position light bulb,
detach the bulb holder from the
headlight body and release the bulb.
• Installation is the reversal of removal.
1. Wire retainer
2. Headlight bulb
3. Position light
T908048
1
2
Warning
Do not reconnect the battery until the
assembly process has been completed.
Premature battery reconnection could
result in ignition of the battery gases
causing risk of injury.
Warning
The bulb becomes hot during use. Always
allow sufficient time for the bulb to cool
before handling.
Caution
When reconnecting the battery, connect
the positive (red) lead first.
T908049
1
2
3

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
