Triumph Thruxton Handbook

101
Maintenance and Adjustment
Rear Light/Licence Plate
Light
Rear Light
1. Rear light lens screws
2. Bulb
Bulb Replacement
• Release the screws securing the rear
light lens.
• Remove the lens.
• The bulb is a bayonet type. To
remove the bulb, gently press
inwards and twist anti-clockwise.
• Installation is the reversal of removal.
Direction Indicator Lights
1. Indicator lens screw
2. Bulb
Bulb Replacement
• The lens on each indicator light is
held in place by screws.
• Release the screws and remove the
lens to gain access to the bulb for
replacement.
T908050
2
1
T908051
1
2

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
