34
General Information
Horn Button
When the horn button is pushed,
with the ignition switch turned to
the ON position, the horn will sound.
Pass Button
When the pass button is pressed,
the headlight main beam will be
switched on. It will remain on as long as the
button is held in and will turn off as soon as
the button is released.
Brake and Clutch Lever
Adjusters
1. Lever adjuster wheel
An adjuster is fitted to the front brake and
clutch levers (all models except on
Bonneville T100 and Thruxton). The adjusters
allow the distance from the handlebar to the
lever to be changed to one of four positions,
to suit the span of the operator's hands.
To adjust a lever, push the lever forward and
turn the adjuster wheel to align one of the
numbered positions with the triangular mark
on the lever pivot (seen aligned with
position 4 above).
The distance from the hand grip to the
released lever is shortest when set to number
four and longest when set to number one.
