Triumph Thruxton Handbook

28
General Information
Tachometer (where fitted)
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). On the
right side of the tachometer face is the 'red
zone'. Engine rpm (r/min) in the red zone is
above maximum recommended engine
speed and is also above the range for best
performance.
Warning Lights
Direction Indicators
When the direction indicators are
switched on, the direction indicator warning
light will flash on and off at the same speed.
High Beam
When the headlights are switched
on and the headlight dip switch is
set to 'high beam', the high beam warning
light will illuminate.
Neutral
The neutral warning light indicates
when the transmission is in neutral
(no gear selected). The warning light will
illuminate when the transmission is in neutral
with the ignition switch in the ON position.
Engine Management
System Malfunction
Indicator Light
The malfunction indicator light for the engine
management system illuminates when the
ignition is switched on (to indicate that it is
working) but should not become illuminated
when the engine is running.
If the malfunction indicator light becomes
illuminated when the engine is running, this
indicates that a fault has occurred in one or
more of the systems controlled by the engine
management system. In such circumstances,
the engine management system will switch to
'limp-home' mode so that the journey may
be completed, if the fault is not so severe that
the engine will not run.
Caution
Never allow engine rpm to enter the 'red
zone' as severe engine damage may result.

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
