Triumph Thruxton Handbook

94
Maintenance and Adjustment
Battery Removal
1. Battery
2. Negative (-) terminal
3. Positive (+) terminal
4. Engine control module (ECM)
• Remove the seat as described in the
General Information section.
• Disconnect the battery leads,
negative (black) lead first.
• Remove the battery strap.
• Take the battery out of the case.
Note:
• The Engine Control Module (ECM)
is located at the rear of the battery
tray and is secured to the
motorcycle by the battery. Ensure
the ECM is not disturbed during
the battery removal or installation
process.
Battery Maintenance
Clean the battery using a clean, dry cloth. Be
sure that the cable connections are clean.
The battery is a sealed type and will not
require any maintenance other than checking
the Voltage and routine recharging, such as
during storage.
It is not possible to adjust the battery acid
level in the battery; the sealing strip must not
be removed.
T908045
1
3
2
4
Warning
Ensure that the battery terminals do not
touch any part of the motorcycle as this
may cause a short circuit or spark which
would ignite battery gases causing a risk of
personal injury and damage to the
motorcycle.
Warning
The battery acid is corrosive and poisonous
and will cause damage to unprotected
skin. Never swallow battery acid or allow it
to come into contact with the skin. To
prevent injury, always wear eye and skin
protection when handling the battery.

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
