Triumph Thruxton Handbook

39
General Information
Right Hand Side Cover
(Scrambler only)
1. S i d e c o v e r
2. Retaining dowels/grommets
The right hand side cover can be removed to
gain access to the fuse box.
To remove the side cover, pull the top of the
cover away from the motorcycle until it clears
its retaining dowels (leaving the grommets in
place) and then lift up and remove the cover
from the motorcycle.
To refit, position the lower locating dowels,
then press firmly to secure the cover into the
upper grommets.
Ensure the cover is correctly located over the
upper and lower locating dowels.
Finally, grasp the cover and ensure that it is
fully retained.
Left Hand Side Cover
(Scrambler only)
1. S i d e c o v e r
2. Fastener
3. Seat removal tool
The left hand side cover can be removed to
gain access to the seat removal tool.
To remove the side cover, release the cover's
threaded fastener using a coin.
Lift the cover until it clears its retaining
dowels and then remove the cover from the
motorcycle.
To refit, position the cover over its locating
dowels, fit the threaded fastener and tighten
with a coin.
Finally, grasp the cover and ensure that it is
fully retained.
cdnf
2
1
T908018
3
1
2

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
