102
Maintenance and Adjustment
Cleaning
Frequent, regular cleaning is an essential part
of the maintenance of your motorcycle. If
regularly cleaned, the appearance will be
preserved for many years. Cleaning with cold
water containing an automotive cleaner is
essential at all times but particularly so after
exposure to sea breezes, sea water, dusty or
muddy roads and in winter when roads are
treated for ice and snow. Do not use
household detergent as the use of such
products will lead to premature corrosion.
Although, under the terms of your
motorcycle warranty, cover is provided
against the corrosion of certain items, the
owner is expected to observe this reasonable
advice which will safeguard against corrosion
and enhance the appearance of the
motorcycle.
Preparation for Washing
Before washing, precautions must be taken
to keep water off the following places:
Rear opening of the exhausts: Cover
with a plastic bag secured with
rubber bands.
Clutch and brake levers, switch
housings on the handlebar: Cover
with plastic bags.
Ignition switch and steering lock:
Cover the keyholes with tape.
Remove any items of jewellery such as rings,
watches, zips or belt buckles, which may
scratch or otherwise damage painted or
polished surfaces.
Use separate cleaning sponges or cleaning
cloths for washing painted/polished surfaces
and chassis areas. Chassis areas (such as
wheels and under mudguards) will be
exposed to more abrasive road grime and
dust, which may then scratch painted or
polished surfaces, if the same sponges or
cleaning cloths are used.
Where to be Careful
Avoid spraying water with any great force
near the following places:
Instruments;
Brake cylinders and brake calipers;
Under the fuel tank;
Drive chain and headstock bearings.
Note:
Use of soaps that are highly
alkaline will leave a residue on
painted surfaces, and may also
cause water spotting. Always use a
low alkaline soap to aid the
cleaning process.
Caution
Do not spray any water at or behind the
left hand side panel. The engine’s air intake
duct is located behind the left hand side
panel and any water sprayed in this area
could enter the airbox and engine, causing
damage to both items.
Caution
Use of high-pressure spray washers is not
recommended. When using pressure
washers, water may be forced into
bearings and other components causing
premature wear from corrosion and loss of
lubrication.

Table of Contents

Other manuals for Triumph Thruxton

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Thruxton and is the answer not in the manual?

Triumph Thruxton Specifications

General IconGeneral
Displacement1200 cc
Transmission6-speed
Bore x Stroke97.6 mm x 80 mm
Max Torque112 Nm @ 4, 950 rpm
Fuel SystemFuel injection
Final DriveChain
ClutchWet, multi-plate
FrameTubular steel
Rear SuspensionTwin shocks
Front BrakesDual 310mm discs, 2-piston calipers
Rear BrakesSingle 220mm disc, 2-piston caliper
Front Wheel17 x 3.5 in
Rear Wheel17-inch
Length2100 mm (82.7 in)
Width (Handlebars)745 mm (29.3 in)
Height1, 030mm
Seat Height810mm
Wheelbase1, 415mm
Rake22.8 º
Fuel Capacity14.5 liters
Weight (Dry)203kg
Weight (Wet)223kg
Exhaust2-into-2
