Triumph Thruxton Handbook

78
Maintenance and Adjustment
Brakes
1. Lining material thickness
2. 1.5 mm (0.06 in) groove thickness
Brake Pad Wear Inspection
Brake pads must be inspected in accordance
with the scheduled maintenance
requirements and replaced if worn to, or
beyond, the minimum service thickness.
If the lining thickness of any pad (front or rear
brakes) is less than 1.5 mm (0.06 in), that is, if
the pad has worn down to the bottom of the
grooves, replace all the pads on the wheel.
Breaking-in New Brake Pads and
Discs
After replacement brake discs and/or pads
have been fitted to the motorcycle, we
recommend a period of careful breaking-in
that will optimise the performance and
longevity of the discs and pads. The
recommended distance for breaking-in new
pads and discs is 200 miles (300 km).
After fitting new brake discs and/or pads
avoid extreme braking, ride with caution and
allow for greater braking distances during the
breaking-in period.
T908039
2
1
Warning
Brake pads must always be replaced as a
wheel set. At the front, where two calipers
may be fitted on the same wheel, replace
all the brake pads in both calipers.
Replacing individual pads will reduce
braking efficiency and may cause loss of
motorcycle control and an accident.
After replacement pads have been fitted,
ride with extreme caution until the new
pads have 'broken in'.

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
