Triumph Thruxton Handbook

38
General Information
Side Cover (all models except
Scrambler)
1. S i d e c o v e r
2. Fastener
3. Seat removal tool
The right hand side cover can be removed to
gain access to the fuse box, seat removal tool,
rear brake fluid reservoir etc.
To remove the side cover, release the cover's
threaded fastener using a coin.
Lift the cover until it clears its retaining
dowels and then remove the cover from the
motorcycle.
To refit, position the cover over its locating
dowels, fit the threaded fastener and tighten
with a coin.
Finally, grasp the cover and ensure that it is
fully retained.
Warning
Overfilling the tank can lead to fuel
spillage.
If petrol (fuel) is spilled, thoroughly wipe off
the spilled fuel immediately and dispose of
the cleaning cloth safely.
Take care not to spill any petrol (fuel) on
the engine, exhaust pipes, tyres or any
other part of the motorcycle.
Because petrol (fuel) is highly flammable,
any fuel leak or spillage, or any failure to
observe the safety advice given above will
lead to a fire hazard which could cause
damage to property, injury to persons or
death.
Petrol (fuel) spilled near to or on the tyres
will reduce the tyre's ability to grip the
road. This will result in a dangerous riding
condition causing loss of motorcycle
control and an accident.
T908018
3
1
2

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
