Triumph Thruxton Handbook

25
General Information
Instruments
Bonneville
Bonneville SE, Bonneville T100, Steve McQueen™ Edition, Bonneville 110
th
Edition,
Scrambler and Thruxton
1. Speedometer
2. Odometer
3. Reset button
4. Low oil pressure warning light
5. Neutral indicator light
6. High beam indicator light
7. Direction indicator light
8. Tachometer location (if fitted)
9. Engine management malfunction
indicator light (MIL)
10.Low fuel level indicator light
11. Alarm status indicator light (alarm is
an accessory fit)
3
2
1
7
6
4
5
10
9
11
8
6
cayb
5
4
7
1
2
3
11
9
10

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
