TSC M23 Programming Manual

TSC AUTO ID Technology Co., Ltd. 2 Copyright 2013 All Rights Reserved.
 GAP
Description
Defines the gap distance between two labels.
Syntax
GAP m,n
English system (inch)
GAP m mm,n mm
Metric system (mm)
GAP m dot,n dot
Dot measurement
This command has been supported since V6.27 EZ and later firmware.
Parameter
Description
M
The gap distance between two labels
0 ≤ m ≤1 (inch), 0 ≤ m ≤ 25.4 (mm)
N
The offset distance of the gap
n ≤ label length (inch or mm)
0, 0
Continuous label
Note :
 200 DPI : 1 mm = 8 dots
300 DPI : 1mm = 12 dots
 For metric and dot systems, there must be a space between parameter and mm.
 When the sensor type is changed from “Black Mark” to “GAP”, please send the “GAP”
command to the printer first.
