TSC M23 Programming Manual

TSC AUTO ID Technology Co., Ltd. 206 Copyright 2013 All Rights Reserved.
 LED1, LED2, LED3
Description
This command is used to control LED on/off. This attribute is write-only. Specify 1 to light on LED and 0
to turn off LED. Before using this command, be sure to cancel the default LED functions. Please refer to
the SET LED command.
Syntax
LEDm = n
Return Value
Description
m
m=1, LED1
m=2, LED2
m=3, LED3
n
0: turn off LED
1: light on LED
Model
LED1
LED2
LED3
LED2 & LED3
TTP-243 series
POWER
ONLINE
ERROR
TTP-243 Plus series
POWER
ONLINE
ERROR
TTP-244ME series
POWER
ONLINE
ERROR
TTP-244ME Plus series
POWER
ONLINE
ERROR
TTP-244 series
POWER
ONLINE
ERROR
TTP-244CE series
POWER
ONLINE
ERROR
TTP-245 series
GREEN
GREEN
RED
ORANGE
TTP-245C series
GREEN
GREEN
RED
ORANGE
TDP-245 series
GREEN
GREEN
RED
ORANGE
TTP-246M series
POWER
ONLINE
ERROR
TTP-248M series
POWER
ONLINE
ERROR
TTP-2410M series
POWER
ONLINE
ERROR
TDP-643 Plus
ONLINE
ERROR
ERROR
TDP-643R Plus
ONLINE
ERROR
ERROR
TTP-342 series
POWER
ONLINE
ERROR
TTP-342 Plus series
POWER
ONLINE
ERROR
TTP-342M series
POWER
ONLINE
ERROR
TTP-342M Plus series
POWER
ONLINE
ERROR
TTP-343 series
GREEN
GREEN
RED
ORANGE
TTP-343C series
GREEN
GREEN
RED
ORANGE
TTP-344M series
POWER
ONLINE
ERROR
TTP-346M series
POWER
ONLINE
ERROR
TTP-384M series
POWER
ONLINE
ERROR
TTP-644M series
POWER
ONLINE
ERROR
M23 series
Note:
For TTP-245/343/TDP-245 series, the LED1=LED2.
Example
Sample code
DOWNLOAD "DEMO.BAS"
SIZE 3,3
GAP 0.12,0
SPEED 4
DENSITY 8
DIRECTION 1
