Ubee Interactive Using the WLAN Option
Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017 47
6.3 Using the WLAN Option
Use the WLAN (wireless local area network) option to configure wireless network settings.
For assistance in deploying and troubleshooting the wireless network, refer to Deploying
and Troubleshooting the Wireless Network on page 94.
To view WLAN interface information:
1. Click Gateway from the main menu.
2. Click WLAN on the left side menu.
3. The following sub-menus are available for selection:
Using the Basic Option on page 47
Using the Security Option on page 49
Using the WPS Option on page 51
Using the Access Control Option on page 52
Using the WMM Option on page 54
6.3.1 Using the Basic Option
The WLAN Basic option allows you to configure basic settings for both the 2.4GHz and
5GHz radio bands, including channel number and bandwidth control. You can also
change the SSID (wireless network name) here.
NOTE: The UBC1303AB00 is a dual-band concurrent
wireless gateway, supporting
operation of both the 2.4GHz and 5GHz radio bands simultaneously. Both radios are
enabled by default.
To configure basic wireless settings:
1. Click WLAN from the left side menu.
2. Click Basic under WLAN.
Field descriptions follow the screen example.
