Ubee UBC1303 User Manual

Ubee Interactive Using the WLAN Option
Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017 51
6.3.3 Using the WPS Option
Use the WPS option for automatic security configuration for devices connecting to the
wireless network using WPS (Wi-Fi Protected Setup) without the need to know the
encryption type, network name (SSID), or pre-shared key.
To connect via WPS:
1. Click WLAN from the left side menu.
2. Click WPS under WLAN.
Field descriptions follow the screen example.
Pre-Share
Key
Displays the pre-shared key when WPA or 802.1x network authentication is used. The pre-shared
key is a unique key for each device, also called the network key, the wireless key, or the wireless
password. The pre-shared key for the UBC1303AB00 is a randomly generated character string, 10
characters in length, and is printed on the device label.
Note: The pre-shared key is visible when click the “Show Key” box as seen below.
If you want to change the pre-share key, highlight the current key as shown below.
Delete the default pre-share key and type in the password of your choice, then click Apply.
Protected
Management
Frame
Allows you to set the protected management frame option. Options are: Off, Capable, and
Required.
Apply Saves changes.
Cancel Cancels the changes.
Label Description
