Ubee UBC1303 User Manual

Ubee Interactive Using the Advanced Settings Options
Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017 74
6.4.8 Using the DMZ Option
Use the DMZ (Demilitarized Zone) option to expose a host IP address to the WAN (public
Internet). A DMZ allows one IP address (or computer) to be placed in between the firewall
and the Internet (usually for gaming and video conferencing). This allows risky, open
access to the Internet. You can use this option when applications do not work with port
triggers or other networking strategies.
To set up a DMZ host:
1. Connect a PC to an Ethernet port on the UBC1303AB00. Make sure both devices are
powered on and functioning.
2. Connect a Home Gateway (or other device you wish to be in the DMZ) to an Ethernet
port on the UBC1303AB00.
3. Log in to the UBC1303AB00 Web user interface.
4. Click Gateway from the top main menu.
5. Click Advanced Settings from the left side menu.
6. Click DMZ under Advanced Settings.
7. Enter the DMZ Host IP address in the appropriate field.
8. Test the device to ensure Internet access is available and the device is functional. For
example, connect to the Internet from a PC connected to the Home Gateway, or make
calls from a VoIP phone.
Label Description
DMZ Host IP Address Allows you to enter the IP address of the host to be exposed.
Save/Apply Saves changes.

Ubee UBC1303 Specifications

General

Brand	Ubee
Model	UBC1303
Category	Gateway
Language	English
