Ubee Interactive Using the WLAN Option
Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017 49
6.3.2 Using the Security Option
Use the Security option to configure a variety of wireless security settings for both the
2.4GHz and 5GHz radio bands.
To configure wireless security:
1. Click WLAN from the left side menu.
2. Click Security under WLAN.
Field descriptions follow the screen example.
WMM Support
When WMM (WiFi Multimedia) support in on, quality of service (QoS) is enabled to
ensure the best service in your wireless network.
Control Channel
Selects a specific channel to deploy the wireless network. This allows you to set the
operating frequency/channel depending on your particular region. Channel selection
can have an impact on wireless networking performance. The current channel number
is displayed as well as the interference level. Available channels for selection are:
2.4GHz: Auto, 1, 2, 3, 4, 5, 6, 7, 8, 9
5GHz: Auto, 36, 52, 100, 116, 40, 56, 104, 120, 44, 60, 108, 124, 48, 64, 112,
128
For more information regarding channels selection, refer to Selecting a Wireless
Channel on page 98
Bandwidth
Sets the channel bandwidth and displays the current channel bandwidth. Available
bandwidths for selection are:
2.4GHz: 20MHz, 40MHz
5GHz: 20MHz, 40MHz, 80MHz
NOTE:
802.11b and 802.11g support 2.4GHz, 20MHz wide channels
802.11n supports 2.4GHz or 5GHz, 20MHz or 40MHz wide channels
802.11a supports 5GHz, 20MHz wide channels
802.11ac supports 5GHz, 20MHz, 40MHz or 80MHz wide channels
Sideband for
Control Channel
Only when using 40MHz bandwidth should you choose the lower or upper 20MHz.
Apply Saves changes.
Restore Wireless
Defaults
Restores the factory default settings for wireless configurations when clicked.
Label Description
