Ubee Interactive Using the Advanced Settings Options
Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017 64
6.4.3 Using the IP Filter Option
Use the IP Filter option to filter IP addresses to block Internet traffic to specific network
devices on the LAN. Any host on this list is not accessible to Internet traffic.
NOTE: You may also filter by the MAC address which does not require setting a static
lease. Refer to Using the MAC Filter Option on page 66.
To set up IP Filters:
1. Click Advanced Settings from the left side menu.
Label Description
Firewall Level
IPv4 Firewall
Protection
Defines the level of IPv4 protection. Choices are Off, Low, Medium, High. Services are
based on the protection level and are displayed in the Allowed Services section.
IPv6 Firewall
Protection
Defines the level of IPv6 protection. Choices are On and Off. Services are based on the
protection level and are displayed in the Allowed Services section.
Firewall Options
Enable WAN
Blocking
When enabled, WAN Blocking blocks PING access to the WAN public gateway IP address
that is exposed to the Internet. When disabled, PING access is allowed to occur, which is
necessary for the remote configuration of some VoIP phones (e.g. Cisco, Polycom, etc.).
Enable Dropping
Fragments
When enabled, Dropping Fragments prevents all fragmented IP packets from passing
through the firewall.
Allowed Services Lists the allowed services based upon the selected firewall levels and options.
Apply Saves changes.
