184 Individual phone configuration
Network information
This overview in the user area of the Service menu provides you with information
about the IP address of the phone and the HTML address of the web interface.
It also provides real-time data about the network activity of the phone.
N Press the key shown.
Select and confirm the option shown.
Select and confirm the option shown.
if nec.j Enter and confirm the user password.
Select and confirm the option shown. You can browse the following overview:
IP Address: Displays the IP address or name which was assigned to the phone
in the network.
WBM URL: HTTP address of the web interface. This address is specified in the
address line of the Internet browser and is used to call the web interface of the
phone in the browser.
DNS domain: The DNS domain that can be assigned to the telephone in addi-
tion to the IP address (e.g. http://my-openStage.phone/).
LAN/PC-RX: The network or PC interface data packets received are illustrated
dynamically as columns.
LAN/PC-TX: The network or PC interface data packets sent are illustrated dy-
namically as columns.
LAN/PC autonegotiated: [Yes|No]: Displays whether the network or PC inter-
face data transfer rate is set to automatic (Yes) or manual (?No).
LAN/PC information: [10|100|1000] Mbit/s: Data transfer rate of the network
or PC interface. If an interface is not in use, Link
down is displayed.
