Call recording 195
Diagnostic information
This information overview in the user area of the service menu provides you with
information on the current configuration of the telephone:
N Press the key shown.
Select and confirm the option shown.
Select and confirm the option shown.
if nec. j Enter and confirm the user password.
Select and confirm the option shown.
You see a numbered list of telephone parameters with the current settings.
You can see a more structured view of the list via the WBM interface
 Page 197:
Example:
Settings
User
Diagnostic information
Diagnostic Information
2011-05-23 12:24:00
00 terminal.number: 3334
01 sip.server: 192.168.1.240
02 sip.port: 5060
03 sip.registrar: 192.168.1.240
04 sip.registrar.port: 5060
05 sip.gateway: 192.168.1.240
06 sip.transport: UDP
07 sip.gateway.port: 5060
08 server.features: No
09 dns.results: 5060
10 multiline: No
11 registered.lines: 5060
12 backup.active: Yes
13 backup.proxy:
14 software.version: V3 R0.24.0 SIP 110514
15 display.message: None
16 last.restart: 2011-05-19T13:42:02
17 memory.free: 23131K free
18 ip.adress: 192.168.1.203
19 subnet.mask: 255.255.255.0
20 default.route: 192.168.1.2
21 primary.dns: 192.168.1.105
22 secondary.dns: 192.168.1.2
23 route.1.ip:
24 route.1.gateway: None
