Unify OpenStage User Manual

c04.fm
A31003-S2000-R102-16-7620, 02/2016
Provisioning Service, Developer’s Guide
103
Nur für den internen Gebrauch Phone Parameters - Administration
Network
4.3.6 Port configuration
Layer 3 signalling l3qos-
signalling
Enumer-
ation
0=BE;
10=AF11;
12=AF12;
14=AF13;
18=AF21;
20=AF22;
22=AF23;
24=CS3;
26=AF31;
28=AF32;
30=AF33;
32=CS4;
34=AF41;
36=AF42;
38=AF43;
40=CS5;
46=EF;
56=CS7;
Default: 26
Sets the layer 3 CoS
(Class of Service) value
for signaling.
Priority Not applicable.
Immediate Not applicable.
Flash Not applicable.
Flash override Not applicable.
WBM Name Item name Type Values Description
SIP server reg-port Integer Port number
Default: 5060
Port of the SIP proxy
server.
SIP registrar registrar-
port
Integer Port number
Default: 5060
Port of the server at which
the phone registers.
SIP gateway sgnl-
gateway-
port-user
Integer Port number
Default: 5060
Port of the SIP gateway.
SIP local phone-port Integer Port number
Default: 5060
Port used by the phone
for sending and receiving
SIP messages.
WBM Name Item name Type Values Description
