2-13
Installing and Setting up the Machine > Default Settings of the Machine
Network Setup (LAN Cable Connection)
The machine is equipped with network interface, which is compatible with network protocols such as TCP/IP (IPv4),
TCP/IP (IPv6), NetBEUI, and IPSec. It enables network printing on the Windows, Macintosh, UNIX and other platforms.
This section explains the procedure of IPv4 settings for TCP/IP settings. The default settings are "TCP/IP Protocol: On,
DHCP: On, Auto-IP: On".
1
Display the screen.
1 Press the [Status/System Menu/Counter] key.
2 Press the [ā²] or [ā¼] key to select [System/Network], and press the [OK] key.
3 Press the [ā²] or [ā¼] key to select [Network Setting], and press the [OK] key.
4 Press the [ā²] or [ā¼] key to select [TCP/IP Settings], and press the [OK] key.
ā¢ If user login administration is enabled, you can only change the settings by logging in with administrator privileges.
If user login administration is disabled, the user authentication screen appears. Enter a login user name and
password, and press [Login].
The factory default login user name and login password are set as shown below.
ā¢ Ask your network administrator for the IP address in advance, and have it ready when you configure this setting.
In the following cases, set the IP address of DNS server on the Embedded Web Server RX.
- When using the host name with "DHCP" setting set to "Off"
- When using the DSN server with IP address that is not assigned by DHCP automatically.
Refer to the Embedded Web Server RX User Guide.
ā¢ For other network settings, refer to the Network Setting
on page 8-8.
Login User Name Login Password
4000 4000
Sys. Menu/Count.:
System/Network
Exit
03
Counter
02
01
Report
System/Network:
Network Setting
Exit
01
Optional Network
02
NW InterfaceSend
03
Network Setting:
TCP/IP Settings
Exit
01
WSD-SCAN
02
WSD-PRINT
03
To Next Page
