Vatech A9 (PHT-30CSS)

Technical manual

VDH-TeM-098

88 / 214

6. DAP Calibration

1. The position of the dosimeter is fixed at the position shown above.

Make sure the end of the

dosimeter is l

ocated on the

line at the bottom of the

sensor.

Position the dosimeter so that it is

centered in the area indicated by

the arrow at the

bottom of the

sensor.

Click the Capture CTB to

acquire dark data and

confirm the position of the

dosimeter (acquir

ed for

about 5 seconds).

2. When the image capture is complete,

Click the V proj button to check the image.
