PaX-i3D Green (PHT-60CFO) User Manual
46
4 Software Overview
4.3
Imaging Software Overview
You can set the imaging parameters on either the touch
screen or the imaging program running on the PC. They are
synched in real time and display the same environmental
settings. For more details on the Touch Screen, refer to
“3.3.2 Touch Screen”.
Imaging parameters can be set using the imaging program. The following
screenshot shows the main interface in PANO mode. For details concerning
PANO, CEPH and CBCT imaging, refer to sections
4.3.1 - 4.3.3.
A. Imaging Mode Display
This displays the current imaging mode.
:
- Indicates that the Magic PAN is supported in the PANO
imaging modality.
- Is displayed only for the Standard mode, with the Magic
PAN enabled.
A
I K
G H
L
O
P
N
M
B
C
D
E
F
J
[PI3DG_130U_44A_en]User Guide.indd 46 2016-05-24 오후 4:18:39
