PaX-i3D Green (PHT-60CFO) User Manual
77
6 Acquiring PANO Images
6.2
Setting Exposure Parameters
Perform the following procedures to select the capture parameters for the
specic patient and capture mode. For more details, refer to
4.3.1 PANO.
You can set the imaging parameters on either the touch screen
or the imaging program running on the PC. They are synched
in real time and display the same environmental settings.
Imaging Program
Touch Screen
A. Choose an imaging mode under
Imaging Mode.
B. Select the mode under PANO Type:
Normal or Magic PAN.
Mode Details
Normal
Normal image.
Magic PAN
Image with ultra-high resolution optional
C. Select the image quality for the image.
Mode Details
HD
Image with higher resolution than Normal. Takes longer
scan time than the Normal.
Normal
Normal image
A
B
C
D
E
