PRODUCT SPECIFICATIONS
GENERAL SPECIFICATIONS FOR ALL INTUOS4 TABLETS
INTUOS4 S TABLET (MODEL PTK-440)
INTUOS4 M TABLET (MODEL PTK-640)
Aspect ratio 16 : 10
Coordinate resolution 200 lpmm (5080 lpi)
Accuracy, pen +/- 0.25 mm (0.010 in)
Accuracy, mouse +/- 0.5 mm (0.020 in)
Accuracy, lens cursor +/- 0.15 mm (0.006 in) (PTK-1240), +/- 0.25 mm (0.01 in) (PTK-840)
Tilt range (all pens) +/- 60 degrees (+/- 50 degrees on Intuos4 S tablets)
Reading height 10 mm (0.39 in)
Maximum report rate 200 points per second
ExpressKeys stroke 1 mm (0.04 in), approximately
Communication interface USB
Connector USB Type A to USB mini-B (Intuos4 S, M, and L tablet models)
USB Type A (Intuos4 XL)
Cable length 2.5 m (8.2 ft)
Power requirements DC 5V, less than 300 mA, from primary USB port or powered USB hub
Operating temperature 5 to 40 degrees C (41 to 104 degrees F)
Storage temperature -15 to +55 degrees C (5 to 131 degrees F)
Operating relative humidity 30% to 80% non-condensing
Storage relative humidity 30% to 85% non-condensing
Certification and compliance FCC class B, CE, VCCI Class B, BSMI, C-Tick, MIC, GOST-R, RoHS,
Chinese RoHS, Industry Canada Class B
Active area (W x D) 157.5 x 98.4 mm (6.2 x 3.9 in)
Physical size (W x D x H) 309 x 208 x 12 mm (12.2 x 8.2 x 0.5 in), approximately
Weight 700 g (1.54 lb), approximately
Active area (W x D) 223.5 x 139.7 mm (8.8 x 5.5 in)
Physical size (W x D x H) 370 x 254 x 12 mm (14.6 x 10.0 x 0.5 in), approximately
Weight 1 kg (2.2 lb), approximately
