Installation- and operating manual Handling device HP140T R09-2011
28/52
Installation
5.1 Safety during installation
5
5 Installation
5.1 Safety during installation
Particularly ensure that:
• only authorised persons are in the work area and that no other persons are endange-
red by the assembly work.
• no components are damaged and are only installed in a clean, functional condition.
• all components are installed according to the described instructions.
• specified starting torques are adhered to.
• the key aspect of the structural components is taken into consideration.
5.2 Installation prerequisites
Check prior to installation whether the dimensions of the installation site and building
conditions correspond to the necessary prerequisites and measurement specification in
the drawing documents.
Particularly ensure that:
• The supporting floor is level and rigid.
• The dimensions of the supporting structure at the installation location must be suf-
ficient to withstand the dynamic forces that occur. Forces of up to 350 N can occur.
Injuries caused by incorrect installation.
The dimensions of the supporting ground and fastening equipment must sufficient, so that
they can withstand the stresses produced during operation.
Work should only be assigned to auxiliary personnel by company installation personnel.
Injuries caused by sharp-edged machine parts which are still uncovered and acces-
sible.
Wear personal protective clothing.
Injuries caused by falling loads.
Parts stacked on top of each other can slip and fall. Do not loosen any fixing elements
and transportation securing devices without the express instructions of the company
installation personnel. Wear personal protective clothing.
