140 6 Troubleshooting
Paper Jams in the Output Area
1. Remove the jammed paper.
2. If paper is jammed inside the top cover, pull
the front cover release levers ("A") on both
sides of the printer towards you and open
the front cover. Then open the top cover.
3. Remove the jammed paper.
Important
• The fuser is hot. Do not touch areas with labels
indicating high temperature and those surrounding the
labels. Otherwise, you can get burnt.
4. Close the top cover and then the front
cover.
Important
• When closing the front cover, be careful not to get your
fingers caught between (the left, right, top, or bottom
edge of) the cover and the printer.
To Next Page
