Xerox DocuPrint 2065 User Manual

A.6 Installing the Internal Hard Disk 213
Installation Procedure
The internal hard disk goes into the controller board right above a font ROM or PostScript
®
ROM. If you purchased one of these ROMs, install it before installing the internal hard disk.
For information on how to install a ROM to the printer, refer to the installation guide provided
for the ROM.
Follow these steps when installing the internal hard disk to the printer.
When uninstalling the internal hard disk, use the reverse procedure described below.
1. Switch the power off by pressing the power
switch located on front lower right of the
printer to the <O> position.
Unplug the power cord from the power
outlet and the printer.
2. Remove the two screws that secure the
rear cover to the printer.
3. Pull the rear cover forward and remove it
from the printer.
PostScript ROM or
font ROM
Hard disk
