A.8 Installing the KR Font Kit 221
Installation Procedure
The ROM of the KR font kit goes into the controller board right underneath an internal hard
disk (optional). If your printer has an internal hard disk, remove it to get an access to the
ROM slot. For information on how to uninstall/re-install the internal hard disk, refer to "A.6
Installing the Internal Hard Disk" (P. 212)
Follow these steps when installing the KR font ROM to the printer:
1. Switch the power off by pressing the power
switch located on the front lower right of the
printer to the <O> position.
Unplug the power cord from the power
outlet and the printer.
2. Remove the two screws that secure the
rear cover to the printer.
3. Pull the rear cover forward and remove it
from the printer.
Internal hard disk
Font ROM
To Next Page
