Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345

Service Manual

5-19

Parts List 3.2 Bypass Tray

Item Name Part Number

1MP Taptype Screw -

2Idle Holder MP -

3Roller Cover -

4Idler Roller -

5ETC Pin -

6CS Spring -

7Lower MP -

8 Empty MP Actuator -

9Lower MP Guide -

10 Bypass Tray Paper Entry Sensor 130N01574

11 Cassette Pad RPR -

12 TS Spring -

13 CS Spring -

14 Retard Roller Cassette (Retard Roller) (Includes 15, 16) 022N02677

15 Torque Limiter Coupler -

16 TL Rubber -

17 Retard Shaft Holder 006N01347

18 Upper MP -

19 Arm MP Actuator -

20 Upper MP Guide -

21 Brush PMO -

22 MP Stopper -

23 ES Spring -

24 Pick Up MP (Bypass Tray Pick Up Assembly) 130N01675

25 MP Collar -

26 Idle Pick Up Gear -

27 Joint Gear -

28 Joint2 MP Gear -

29 Shaft Holder -

30 Pick Up MP Housing -

31 Pick Up Clutch Sub PMO -

32 Pick Up Rubber -

33 Pick Up Sub Shaft -

34 Pick Up MP Shaft -

35 MP Clutch Sleeve -

36 MP Sleeve -

37 TS Spring -

38 Plain Washer -

39 MP (Bypass Tray) 130N01676
