Xerox Phaser 3330 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-9
Printer Routines
(con’t)
DC 330 Component Control
(con’t)
07-210 T2 Paper Empty Sensor
07-510 Bypass Paper Empty Sensor
08-100 Feed Sensor
08-200 T2 Feed Sensor
08-500 Regi. Sensor
08-720 Out-Bin Full Sensor
08-810 T1 Pick-Up Clutch
08-820 T2 Pick-Up Clutch
08-920 T2 Feed Motor Run
09-100 MHV Bias
09-200 Dev Bias
09-300 THV(+) Bias
09-310 THV Bias Read
09-400 THV(-) Bias
09-500 SMPS Fan Run
10-200 Fuser Temperature A
10-500 Fuser Fan Run
10-600 Fuser Bias
DC 305 UI Test LCD Display
Complete UI Test
Other Routines Memory Clear Yes/No
Format SD Yes/No
Set Machine Serial Number
Log Backup Capture Log Insert USB Memory
Log Backup OnOff Off
Level 1
Level 2
Exit Diagnostics Yes/No
LEVEL 1 LEVEL 2 LEVEL 3

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
