Page 4-4 Xerox WorkCentre 4118 System Administration Guide
Print Driver Installation for Networked Printers
Windows XP (TCP/IP)
NOTE: Windows XP supports printing via TCP/IP as standard when TCP/IP is
installed on a Windows XP Workstation.
Ensure you have the correct drivers CD (part number 705N00017 for PCL or
705N00021 for PostScript) prior to starting this procedure.
Use the Add Printer Wizard to add the WorkCentre 4118 to the network.
¾ Select [Start], select [Printers and Faxes].
Double-click on the [Add Printer] icon to display the Add Printer Wizard.
¾ Select [Local Printer attached to this computer], uncheck the box labelled [Automatically
detect and install my Plug and Play printer] and then select [Next] to display the dialog box
listing available ports.
¾ Select [Create a new port] to display the Printer Ports dialog box.
Select [Standard TCP/IP Port] and select [Next] to display the Add Standard TCP/IP Port
dialog box.
Enter the IP Address of the printer in the [Name or address of printer] field (you can
optionally enter a friendly name for the printer port you are creating or use the default
name created). Then select [Next] to continue.
If the network printer settings are not automatically detected, click on the [Custom] button
to setup the network printer port settings.
It is recommended that you select [RAW] as the Print Protocol.
If you prefer to use LPR:
Select [LPR] as the Print Protocol.
Enter [lp] (in lower case) in the [LPR print queue] field.
Uncheck the box labelled [LPR Byte Counting Enabled].
Check the box labelled [SNMP Status Enabled].
The [Community Name] should normally be set to public (unless you have configured the
device to have a custom SNMP community name) and the [SNMP Device Index] should
be set to 1.
Select [OK].
¾ The Add Printer Wizard will then request that you select the driver to be used for this
printer.
1
2
3
4
